Suspension Clamp

Suspension clamps are used to hang conductors or ground wires to insulators or link fittings to tower arms and substation structures. WINNING® suspension clamps are made of Aluminum Alloy or Malleable Iron materials with various types. Custom size and requirements are available upon request.

Scope(Drawings are listed in the catalogue, please go to DOWNLOAD chapter.)

1-XGU Suspension Clamp(Trunnion Type)

2-XGU Suspension Clamp (With Socket-Clevis Eye)

3-XGU Suspension Clamp (With U-Type Clevis)

4-XGU Suspension Clamp (Abrasion-Proof Type)

5-XGF (CGF) Aluminum Alloy Suspension Clamp (Hand-down Type)

6-XGF (CGF) Aluminum Alloy Suspension Clamp (Carried-up Type)

7-XGH Aluminum Alloy Suspension Clamp (Envelope Type)

8-XGJ Suspension Clamp

9-XGT (CGT) Suspension Clamp for Twin Conductors

10-CTS (XTS) Suspension Clamp for Twin Jumper Conductors

11-CS Aluminum Alloy Suspension Clamp for Twin Jumper Conductor

12-XCS (CCS) Aluminum Alloy Suspension Clamp for Twin Conductors

13-XT Aluminum Alloy Suspension Clamp for Four Jumper Conductors

14-Top Clamp for Horizontal Line Post Insulators
